GC E612(S)
GC E612S is a 6X12 USSMESH coconut shell activated carbon mainly used for gold recovery.
Manufacturer: IGCL
Place of origin: India
Product Introduction
1. General Introduction
GC E612 is a is a 6X12 USSMESH coconut shell activated carbon mainly used for gold recovery. Compare to GC E612, it offers higher R and K value. It is a supreme high activity granular activated carbon manufactured by steam and air activation from carefully selected coconut shell charcoal and ideally suited for the recovery of precious metals in all forms of contactors providing good adsorption and elution characteristics. GC E612S exhibits a highly developed pore structure to give maximum adsorption while maintaining high product hardness. This results in a high resistance to attrition contributing to lower gold losses in the circuit and during regeneration. As a result, make-up requirements are minimized thus reducing the cost of operation.
The material is packaged in 500kgsnet in poly woven bags or 25kgsnet in PP bags with inner lining will be shrink wrapped and palletized in to fumigated Pallets as per ISPM 15 standard. Store the material in a cool dry area, away from sunlight. More than 5 Years when keeping in proper packed condition.
2. Technical Datasheet
SPECIFICATION | VALUE | TEST METHOD |
CTC activity | Min. 60% | ASTM D3467 |
Total ash content | Max. 3% | ASTM D2866 |
Moisture content | Max. 5% | ASTM D2867 |
Apparent density | Min. 480kg/m³ | ASTM D2584 |
Iodine | 1100 mg/gm | ASTM D4607 |
PH | 9-11 | ASTM D3838 |
Ball Pan Hardness | min. 99% | ASTM D3802 |
Platelets (A.A.R.L.) | max. 4% | AARL |
Attrition (A.A.R.L.) | max. 2% | AARL |
Mean particle diameter (6x12 mesh) | min. 2.48 mm | ASTM 2862 |
Typical Properties | ||
Surface area | 1150 m²/g | BET-m2 |
K value | 29 kg/ton | AARL |
R value | 58% | AARL |
Typical Applications | ||
Carbon-in-pulp (CIP) circuits | ||
Carbon-in-leach (CIL) circuits | ||
Carbon-column (CIC) processes | ||
Silver recovery from photographic wastes | ||
Reworking of ore spoil tips | ||
3. Package and Delivery
Package Method | 40HC Load Quantity | 40HC Load Net Weight | 40HC Load Gross Weight |
550KG Bag | 44 Bags | 24,200Kgs | 24,500Kgs |
25KG Bag | 44 pallets | 22,000Kgs | 23,000Kgs |
